Create a new HTML template to customize your online documentation projects

The recent release of HelpNDoc 6.4 includes an enhanced single page HTML template with the ability to optionally add a table of contents to the produced single page HTML documentation. We obviously used HelpNDoc’s powerful template editor to modify the single page template and we thought it might be a good idea to document this process for learning purposes. Follow the steps described in this article to learn how you can create and alter HTML-based documentation templates using HelpNDoc’s build-in tools.

Using the template editor to create a new template

The HTML documentation files generated by HelpNDoc can be fully customized thanks to the powerful integrated template editor. Let’s see how we can access it and create a new template.

Accessing the template editor is very straightforward: from HelpNDoc’s “Tools” ribbon tab, click the “Template Editor” button to launch it.
As we’d like to create a new template based on the “Single page HTML Template”, we’ll need to duplicate it first:

In the “Template” list, select the “Single page HTML Template (Standard)” item
Click the “Duplicate template” button
Enter the new template’s name

This will create a new template which is identical to the “Single page HTML Template”.

Add custom variables to the newly created template

Some users might prefer their HTML documentation to be generated without a table of contents. Fortunately, templates can include variables to configure their behavior right from within HelpNDoc’s user interface.

Template authors can define variables and use their value to control how the template will behave based on user feedback. HelpNDoc lists all available variables for a specific template in the build window, providing an easy to use interface to customize the template.
Let’s create two variables to control the visibility of the table of contents and its width:

In the template editor, make sure that the newly created template is selected in the “Template” list
Go to the “Variables” section
Click “New Variable”
Specify the following properties to create a boolean variable which will control the visibility of the table of contents:
- Id: “GenerateToc”
- Name: “Generate Table of Contents”
- Description: “If checked, a table of contents will be generated”
- Kind: “bool”
- Default value: “1”
Click “Save”
Click “New Variable” again
Specify the following properties to create a string variable which will control the size of the table of contents:
- Id: “TocWidth”
- Name: “Table of Contents Width”
- Description: “Width of the table of contents. Can be pixels, percent…”
- Kind: “string”
- Default value: “25%”
Click “Save”

Both variables are now created and accessible from both the template’s code for execution, and HelpNDoc’s build dialog for customization.

Edit the template’s script to add the table of contents

Script files control the behavior of the template. Scripts include a mix of HTML and Pascal programming languages to control how the final documentation is generated.

This template only includes a single script which controls the generation of the whole HTML documentation. To edit this script:

In the template editor, make sure that the newly created template is selected in the “Template” list
Go to the “Script files” section
Select the “index.pas.html” script
Click the “Edit Script” button to launch HelpNDoc’s built-in script editor

Let’s first add some CSS styles to customize the look and feel of the generated table of contents. Within the <style type="text/css"> tag, add the following code. Notice how it is included in a conditional statement so that it is only generated when the “GenerateToc” variable is set to “True” from within HelpNDoc’s build window, and how the “TocWidth” variable is used to similarly define the table of content’s width:

<%
    if HndGeneratorInfo.GetCustomSettingValue('GenerateToc') then
    begin
%>

    body {
        align-items: stretch;
        display: flex;
        flex-direction: row;
        flex-wrap: nowrap;
        overflow: hidden;
        margin: 0;
        padding: 0;
    }

    .toc {
        height: 100vh;
        flex: 0 0 <% print(HndGeneratorInfo.GetCustomSettingValue('TocWidth')); %>;
        overflow: auto;
    }

    .content {
        height: 100vh;
        overflow: auto;
    }

    .toc-inner, .content-inner {
        margin: 1em;
    }

    .toc-inner a {
        display: block;
        padding: 0.5em 0 0.5em 0;
        text-decoration: none;
        color: #000;
        font-size: 11pt;
        font-family: 'Segoe UI';
    }

    .toc-inner a:hover {
        background-color: #ddd;
    }

    .toc-inner a.toclevel-2 { padding-left: 1em }
    .toc-inner a.toclevel-3 { padding-left: 2em }
    .toc-inner a.toclevel-4 { padding-left: 3em }
    .toc-inner a.toclevel-5 { padding-left: 4em }
    .toc-inner a.toclevel-6 { padding-left: 5em }
    .toc-inner a.toclevel-7 { padding-left: 6em }
    .toc-inner a.toclevel-8 { padding-left: 7em }
    .toc-inner a.toclevel-9 { padding-left: 8em }
<%
    end;
%>

We can now add the code which will produce the HTML table of contents. Right after the <body> tag, we can add the following code which will iterate through every topic in the project:

<%
    if HndGeneratorInfo.GetCustomSettingValue('GenerateToc') then
    begin
%>
<div class="toc">
    <div class="toc-inner">
        <%
            // Loop through all the topics
            for nCurTopic := 0 to length(aTopicList) - 1 do
            begin
                // Get the topic level
                nTopicLevel := HndTopics.GetTopicLevel(aTopicList[nCurTopic].Id);
                // Add the topic title
                printf(
                    '<a href="#%s" class="toclevel-%d">%s</a>',
                    [aTopicList[nCurTopic].HelpId, nTopicLevel, aTopicList[nCurTopic].caption]
                );
            end;
        %>
    </div>
</div>
<%
    end;
%>

<div class="content">
    <div class="content-inner">

And let’s not forget to close the <div> elements that we created. Right before the </body> tag, we can add:

    </div>
</div>

Use the template to build the HTML documentation

Our newly created template is now ready. It can be used to produce HTML documentation from HelpNDoc’s “Generate documentation” window.

Define build settings and generate documentation

To use our template, we’ll need to assign it to an HTML build:

Open a documentation project in HelpNDoc or create a new one
From HelpNDoc’s “Home” ribbon tab, in the “Project” group, click the top part of the “Generate help” button to show the “Generate documentation” window
Select the HTML build in the list on the left and make sure that it is checked for generation
On the right, click the “Default HTML Template” link and select the newly created template in the list
Click “Customize” if the “Template settings” tab is not already visible
In the “Template settings” tab, make sure that both the “Generate Table of Contents” and “Table of Contents width” are correctly set up. Those are the variables that we defined earlier in the template editor
Click “Generate”

And voilà! HelpNDoc’s generated HTML documentation now includes a table of contents and this template can be reused to any number of documentation projects created in HelpNDoc.

Thanks to this very powerful template system, the HelpNDoc help and documentation authoring environment can be customized to produce truly unique HTML documentation web-sites. HelpNDoc’s template editor and available API methods provide plenty of opportunities to imagine and produce astonishing and tailored documentation files for various supports and audiences.
Feel free to download HelpNDoc now, navigate to its installation directory to review the full source code of the bundled templates, and check the template documentation pages to learn more about their capabilities.
